| Product code | BFC9 P |
|---|---|
| Category | Hydraulic > Hose Tails > BSP Hose Tails |
| Product Code | Thread T | Thread Size | Thread Pipe | Hose Bore DN | Hose Bore Inch | Hose Bore Size | Dimensions mm A | Dimensions mm B | Dimensions mm CH | Dimensions mm D |
|---|---|---|---|---|---|---|---|---|---|---|
| BFC9-0404P | 1/4" - 19 | 4 | 1/4" | 6 | 1/4" | 4 | 17.5 | 6.5 | 19 | 23.5 |
| BFC9-0606P | 3/8" - 19 | 6 | 3/8" | 10 | 3/8" | 6 | 21.5 | 6.5 | 22 | 25.5 |
| BFC9-0808P | 1/2" - 14 | 8 | 1/2" | 12 | 1/2" | 8 | 25.5 | 9 | 27 | 28 |
| BFC9-1212P | 3/4" - 14 | 12 | 3/4" | 20 | 3/4" | 12 | 35.7 | 9 | 32 | 36 |
