| Product code | BF4 T |
|---|---|
| Category | Hydraulic > Hose Tails > BSP Hose Tails |
| Product Code | Thread T | Thread Size | Nominal ID DN | Nominal ID Inch | Nominal ID Dash | Dimensions mm A | Dimensions mm B | Dimensions mm CH | Dimensions mm D |
|---|---|---|---|---|---|---|---|---|---|
| BF4-0404T | 1/4" - 19 | 4 | 6 | 1/4" | 4 | 31.5 | 4.2 | 19 | 13 |
| BF4-0606T | 3/8" - 19 | 6 | 10 | 3/8" | 6 | 39 | 6 | 22 | 15 |
| BF4-0808T | 1/2" - 14 | 8 | 12 | 1/2" | 8 | 46 | 6.5 | 27 | 18 |
| BF4-1212T | 3/4" - 14 | 12 | 20 | 3/4" | 12 | 69.6 | 8.7 | 32 | 28.3 |
| BF4-1616T | 1" - 11 | 16 | 25 | 1" | 16 | 85 | 10.5 | 38 | 32 |
