| Product code | BF9 T |
|---|---|
| Category | Hydraulic > Hose Tails > BSP Hose Tails |
| Product Code | Thread T | Thread Size | Nominal ID DN | Nominal ID Inch | Nominal ID Dash | Dimensions mm A | Dimensions mm B | Dimensions mm CH | Dimensions mm D |
|---|---|---|---|---|---|---|---|---|---|
| BF9-0404T | 1/4" - 19 | 4 | 6 | 1/4" | 4 | 27.5 | 4.2 | 19 | 27 |
| BF9-0604T | 3/8" - 19 | 6 | 6 | 1/4" | 4 | 27.5 | 6 | 22 | 29.5 |
| BF9-0606T | 3/8" - 19 | 6 | 10 | 3/8" | 6 | 32.5 | 6 | 22 | 30 |
| BF9-0806T | 1/2" - 14 | 8 | 10 | 3/8" | 6 | 32.5 | 6.5 | 27 | 32 |
| BF9-0808T | 1/2" - 14 | 8 | 12 | 1/2" | 8 | 39 | 6.5 | 27 | 36.5 |
| BF9-1010T | 5/8" - 14 | 10 | 16 | 5/8" | 10 | 46.5 | 9.5 | 27 | 49 |
| BF9-1212T | 3/4" - 14 | 12 | 20 | 3/4" | 12 | 62.5 | 8.7 | 32 | 58.8 |
| BF9-1616T | 1" - 11 | 16 | 25 | 1" | 16 | 73 | 10.5 | 38 | 71 |
