| Product code | BTM1 R |
|---|---|
| Category | Hydraulic > Hose Tails > BSP Hose Tails |
| Product Code | Thread T | Thread Size | Nominal ID Dash | Nominal ID Inch | Nominal ID DN | Dimensions mm A | Dimensions mm B | Dimensions mm C | Dimensions mm ES |
|---|---|---|---|---|---|---|---|---|---|
| BTM1-0405R | 1/4" - 19 | 4 | 5 | 1/4" | 6 | 26.5 | 14 | 22 | 14 |
| BTM1-0606R | 3/8" - 19 | 6 | 6 | 5/16" | 8 | 29 | 15 | 24 | 19 |
| BTM1-0808R | 1/2" - 14 | 8 | 8 | 13/32" | 11 | 32 | 18 | 27 | 22 |
| BTM1-0810R | 1/2" - 14 | 8 | 10 | 1/2" | 12 | 32.5 | 18 | 31 | 22 |
| BTM1-1212R | 3/4" - 14 | 12 | 12 | 5/8" | 16 | 42 | 20 | 37 | 27 |
| BTM1-1616R | 1" - 11 | 16 | 16 | 7/8" | 22 | 48.1 | 23 | 43 | 36 |
