| Product code | BTM1 F |
|---|---|
| Category | Hydraulic > Hose Tails > BSP Hose Tails |
| Product Code | Thread T | Thread Size | Thread Pipe | Nominal ID DN | Nominal ID Inch | Nominal ID Size | Dimensions mm L | Dimensions mm S1 |
|---|---|---|---|---|---|---|---|---|
| BTM1-0404F | 1/4" - 19 | 4 | 1/4" | 6 | 1/4" | 4 | 26.5 | 14 |
| BTM1-0604F | 3/8" - 19 | 6 | 3/8" | 6 | 1/4" | 4 | 27 | 14 |
| BTM1-0606F | 3/8" - 19 | 6 | 3/8" | 10 | 3/8" | 6 | 29 | 15 |
| BTM1-0806F | 1/2" - 14 | 8 | 1/2" | 10 | 3/8" | 6 | 32 | 18 |
| BTM1-0808F | 1/2" - 14 | 8 | 1/2" | 12 | 1/2" | 8 | 32.5 | 18 |
| BTM1-1212F | 3/4" - 14 | 12 | 3/4" | 20 | 3/4" | 12 | 39 | 20 |
| BTM1-1616F | 1" - 11 | 16 | 1" | 25 | 1" | 16 | 48.1 | 23 |
