| Product code | DSM1 T |
|---|---|
| Category | Hydraulic > Hose Tails > Metric Hose Tails |
| Product Code | Thread T | Thread Size | Thread Pipe | Hose Bore DN | Hose Bore Inch | Hose Bore Size | Dimensions mm A | Dimensions mm B | Dimensions mm ES |
|---|---|---|---|---|---|---|---|---|---|
| DSM1-1604T | M16 x 1.5 | 16 | 8 S | 6 | 1/4" | 4 | 26 | 12 | 17 |
| DSM1-1804T | M18 x 1.5 | 18 | 10 S | 6 | 1/4" | 4 | 26 | 12 | 19 |
| DSM1-2006T | M20 x 1.5 | 20 | 12 S | 10 | 3/8" | 6 | 26 | 12 | 22 |
| DSM1-2206T | M22 x 1.5 | 22 | 14 S | 10 | 3/8" | 6 | 28 | 14 | 22 |
| DSM1-2408T | M24 x 1.5 | 24 | 16 S | 12 | 1/2" | 8 | 28.5 | 14 | 24 |
| DSM1-3612T | M36 x 2 | 36 | 25 S | 20 | 3/4" | 12 | 38 | 18 | 36 |
