| Product code | MAVE |
|---|---|
| Category | Hydraulic > Adaptors > Metric Compression > Tube and Pipe |
| Product Code | Series | Max Working Pressure bar | Tube Ø mm | Port Thread | Thread m | Dimensions mm L1 | Dimensions mm L2 | Dimensions mm L3 | Dimensions mm CH1 | Dimensions mm CH2 | Notes |
|---|---|---|---|---|---|---|---|---|---|---|---|
| MAVE-06LR1/4 | L | 315 | 6 | 1/4 | M12 x 1.5 | 4.5 | 14.5 | 23.5 | 19 | 14 | Non-Stocked |
| MAVE-06SR1/2 | S | 630 | 6 | 1/2 | M14 x 1.5 | 5 | 20 | 25 | 30 | 17 | Non-Stocked |
| MAVE-08LR1/4 | L | 315 | 8 | 1/4 | M14 x 1.5 | 4.5 | 14.5 | 25 | 19 | 17 | Non-Stocked |
| MAVE-08SR1/2 | S | 630 | 8 | 1/2 | M16 x 1.5 | 5 | 20 | 25.5 | 30 | 19 | Non-Stocked |
| MAVE-10LR1/4 | L | 315 | 10 | 1/4 | M16 x 1.5 | 4.5 | 14.5 | 25 | 19 | 19 | Non-Stocked |
| MAVE-10SR1/2 | S | 630 | 10 | 1/2 | M18 x 1.5 | Non-Stocked | |||||
| MAVE-12LR1/4 | L | 315 | 12 | 1/4 | M18 x 1.5 | 4.5 | 14.5 | 26.5 | 19 | 22 | Non-Stocked |
| MAVE-12SR1/2 | S | 630 | 12 | 1/2 | M20 x 1.5 | Non-Stocked |
