MSHA flame resistance approved. FRAS (Fire Resistance Anti-Static). Long life fatigue resistance
| Product code | C25 |
|---|---|
| Type | Two-wire isobaric hose — SAE 100R16, EN857 2SC |
| Standards/Approvals | SAE 100R16; EN857 2SC; ISO 11237 2SC/R16; MSHA flame resistance; FRAS |
| Category | Hydraulic > Hose > Rubber > Braided |
| Inner Liner | Seamless synthetic rubber; resistant to oil |
|---|---|
| Outer Cover | Black synthetic rubber resistant to abrasion, oils, ozone and weathering |
| Reinforcement | Two braids of high-tensile steel wire |
| Application | Isobaric hose for hydraulic fluids including mineral and vegetable oils, aqueous emulsions, water, air and inert gases. Pin-prick the outer cover when conveying air or gases above 17 bar. |
| Temperature range | Ambient: -40°C to +70°C;; Mineral oil: -40°C to +100°C;; Rated range: -40°C to +70°C;; Water: 0°C to +60°C;; Water-based fluids: -40°C to +60°C |
|---|---|
| Safety factor | 4:1 |
| Vacuum rating | -0.2 bar |
| Caution | Prolonged use with water or water-based fluids above 60°C may allow wire corrosion through diffusion across the inner liner. |
| Item code | ID (inch) | ID (mm) | OD avg (mm) | Max WP (bar) | Max WP (psi) | Min bend radius (mm) | Weight (kg/m) | Vacuum rating (bar) |
|---|---|---|---|---|---|---|---|---|
| C25-16 | 1 | 25.4 | 35.6 | 250 | 3626 | 250 | 1.30 | -0.2 |
| Hose size | Crimp |
|---|---|
| -16 | 2J |
