| Product code | JF9 R |
|---|---|
| Category | Hydraulic > Hose Tails > JIC Hose Tails |
| Product Code | Thread T | Thread Size | Thread Pipe | Hose Bore DN | Hose Bore Inch | Hose Bore Size | Dimensions mm A | Dimensions mm B | Dimensions mm CH | Dimensions mm D |
|---|---|---|---|---|---|---|---|---|---|---|
| JF9-0704R | 7/16" - 20 | 7 | 4 | 6 | 1/4" | 4 | 32 | 8.5 | 14 | 30 |
| JF9-0804R | 1/2" - 20 | 8 | 5 | 6 | 1/4" | 4 | 29 | 10.5 | 17 | 30 |
| JF9-0805R | 1/2" - 20 | 8 | 5 | 8 | 5/16" | 5 | ||||
| JF9-0906R | 9/16" - 18 | 9 | 6 | 10 | 3/8" | 6 | 27.8 | 9.5 | 19 | 23 |
| JF9-0906R-056 | 9/16" - 18 | 9 | 6 | 10 | 3/8" | 6 | 27.8 | 9.5 | 19 | 56 |
| JF9-1208R | 3/4" - 16 | 12 | 8 | 12 | 1/2" | 8 | 41.8 | 10.7 | 22 | 30 |
| JF9-1210R | 3/4" - 16 | 12 | 8 | 16 | 5/8" | 10 | ||||
| JF9-1410R | 7/8" - 14 | 14 | 10 | 16 | 5/8" | 10 | 54 | 12.7 | 27 | 52 |
| JF9-1712R | 1.1/16" - 12 | 17 | 12 | 20 | 3/4" | 12 | 55.5 | 13.5 | 32 | 48 |
| JF9-1712R-095 | 1.1/16" - 12 | 17 | 12 | 20 | 3/4" | 12 | 55.5 | 13.5 | 32 | 95 |
| JF9-2116R | 1.5/16" - 12 | 21 | 16 | 25 | 1" | 16 | 72 | 16 | 38 | 71 |
| JF9-2116R-060 | 1.5/16" - 12 | 21 | 16 | 25 | 1" | 16 | 72 | 16 | 38 | 60 |
| JF9-2620R | 1.5/8" - 12 | 26 | 20 | 32 | 1.1/4" | 20 | 81 | 16 | 50 | 80 |
| JF9-3024R | 1.7/8" - 12 | 30 | 24 | 38 | 1.1/2" | 24 | 103 | 18.5 | 55 | 102 |
| JF9-4032R | 2.1/2" - 12 | 40 | 32 | 50 | 2" | 32 | 130 | 24 | 70 | 133 |
