| Product code | JF9 P |
|---|---|
| Category | Hydraulic > Hose Tails > JIC Hose Tails |
| Product Code | Thread T | Thread Size | Thread Pipe | Hose Bore DN | Hose Bore Inch | Hose Bore Size | Dimensions mm A | Dimensions mm B | Dimensions mm CH | Dimensions mm D |
|---|---|---|---|---|---|---|---|---|---|---|
| JF9-0704P | 7/16" - 20 | 7 | 4 | 6 | 1/4" | 4 | 29 | 9 | 14.3 | 29 |
| JF9-0906P | 9/16" - 18 | 9 | 6 | 10 | 3/8" | 6 | 35 | 10 | 17.5 | 28 |
| JF9-1206P | 3/4" - 16 | 12 | 8 | 10 | 3/8" | 6 | 38 | 11 | 22.2 | 32 |
| JF9-1208P | 3/4" - 16 | 12 | 8 | 12 | 1/2" | 8 | 44 | 11 | 22.2 | 39 |
| JF9-1410P | 7/8" - 14 | 14 | 10 | 16 | 5/8" | 10 | 53 | 13 | 25.4 | 50 |
| JF9-1712P | 1.1/16" - 12 | 17 | 12 | 20 | 3/4" | 12 | 58 | 14 | 32 | 54 |
