| Product code | JF1 P |
|---|---|
| Category | Hydraulic > Hose Tails > JIC Hose Tails |
| Product Code | Thread T | Thread Size | Thread Pipe | Hose Bore DN | Hose Bore Inch | Hose Bore Size | Dimensions mm A | Dimensions mm B | Dimensions mm CH | Dimensions mm ES |
|---|---|---|---|---|---|---|---|---|---|---|
| JF1-0704P | 7/16" - 20 | 7 | 4 | 6 | 1/4" | 4 | 20.8 | 8.5 | 14 | 14 |
| JF1-0804P | 1/2" - 20 | 8 | 5 | 6 | 1/4" | 4 | 21.5 | 10.5 | 17 | 14 |
| JF1-0904P | 9/16" - 18 | 9 | 6 | 6 | 1/4" | 4 | 23 | 9.5 | 19 | 14 |
| JF1-0906P | 9/16" - 18 | 9 | 6 | 10 | 3/8" | 6 | 24 | 9.5 | 17.46 | 17 |
| JF1-1206P | 3/4" - 16 | 12 | 8 | 10 | 3/8" | 6 | 26 | 10.7 | 22 | 19 |
| JF1-1208P | 3/4" - 16 | 12 | 8 | 12 | 1/2" | 8 | 26.5 | 10.7 | 22 | 19 |
| JF1-1408P | 7/8" - 14 | 14 | 10 | 12 | 1/2" | 8 | 28.5 | 12.7 | 27 | 22 |
| JF1-1410P | 7/8" - 14 | 14 | 10 | 16 | 5/8" | 10 | 28.5 | 12.7 | 27 | 22 |
| JF1-1710P | 1.1/16" - 12 | 17 | 12 | 16 | 5/8" | 10 | 34 | 14.3 | 32 | 27 |
| JF1-1712P | 1.1/16" - 12 | 17 | 12 | 20 | 3/4" | 12 | 34.5 | 14.3 | 32 | 27 |
| JF1-2116P | 1.5/16" - 12 | 21 | 16 | 25 | 1" | 16 | 36.6 | 16 | 38 | 32 |
