| Product code | JMF1 T |
|---|---|
| Category | Hydraulic > Hose Tails > Speciality > Japanese |
| Product Code | Thread T | Thread Size | Thread Pipe | Hose Bore DN | Hose Bore Inch | Hose Bore Size | Dimensions mm A | Dimensions mm B | Dimensions mm CH | Dimensions mm ES |
|---|---|---|---|---|---|---|---|---|---|---|
| JMF1-1204T | M12 x 1.5 | 12 | 12 | 6 | 1/4" | 4 | 22.5 | 8.7 | 17 | 14 |
| JMF1-1404T | M14 x 1.5 | 14 | 14 | 6 | 1/4" | 4 | 24 | 10 | 19 | 19 |
| JMF1-1406T | M14 x 1.5 | 14 | 14 | 10 | 3/8" | 6 | 25 | 10 | 19 | 19 |
| JMF1-1606T | M16 x 1.5 | 16 | 16 | 10 | 3/8" | 6 | 23.2 | 9.3 | 22 | 19 |
| JMF1-1806T | M18 x 1.5 | 18 | 18 | 10 | 3/8" | 6 | 24 | 11.5 | 24 | 19 |
| JMF1-2006T | M20 x 1.5 | 20 | 20 | 10 | 3/8" | 6 | 25.3 | 11.2 | 27 | 19 |
| JMF1-2206T | M22 x 1.5 | 22 | 22 | 10 | 3/8" | 6 | 25.5 | 14 | 27 | 19 |
| JMF1-2208T | M22 x 1.5 | 22 | 22 | 12 | 1/2" | 8 | 27 | 14 | 27 | 22 |
| JMF1-2408T | M24 x 1.5 | 24 | 24 | 12 | 1/2" | 8 | 28.4 | 15.1 | 32 | 24 |
| JMF1-2410T | M24 x 1.5 | 24 | 24 | 16 | 5/8" | 10 | 28.4 | 15.1 | 32 | 24 |
| JMF1-2412T | M24 x 1.5 | 24 | 24 | 20 | 3/4" | 12 | 29.9 | 15.1 | 32 | 27 |
| JMF1-3012T | M30 x 1.5 | 30 | 30 | 20 | 3/4" | 12 | 33.2 | 18.3 | 36 | 30 |
| JMF1-3312T | M33 x 1.5 | 33 | 33 | 20 | 3/4" | 12 | 32.2 | 21.3 | 41 | 32 |
