Male Stud Coupling with Swivel Nut – Metric / BSPP Elastomer Seal (ED)

21+

Locations New Zealand Wide

65+

Mobile Service Units

24/7

On-Site Hose Repair

METRIC COMPRESSION

Product Details

Product code	EVGE
Category	Hydraulic > Adaptors > Metric Compression > Tube and Pipe

Product Table

Product Code	Series	Max Working Pressure bar	Tube Ø mm	Thread m	Port Thread	Dimensions mm L1	Dimensions mm L2	Dimensions mm CH1	Dimensions mm CH2	Notes
EVGE-06LR1/8ED	L	500	6	M12 x 1.5	1/8	24.5	8	14	14	Body only
EVGE-08LR1/4ED	L	500	8	M14 x 1.5	1/4	29.5	12	19	17	Body only
EVGE-10LR1/4ED	L	500	10	M16 x 1.5	1/4	27.5	12	19	19	Body only
EVGE-12LR3/8ED	L	400	12	M18 x 1.5	3/8	34	12	22	22	Body only
EVGE-15LR1/2ED	L	400	15	M22 x 1.5	1/2	32	14	27	27	Body only
EVGE-18LR1/2ED	L	400	18	M26 x 1.5	1/2	31.5	14	27	32	Body only
EVGE-22LR3/4ED	L	400	22	M30 x 2	3/4	32.5	16	32	36	Body only
EVGE-28LR1ED	L	250	28	M36 x 2	1	35	18	41	41	Body only
EVGE-35LR11/4ED	L	250	35	M45 x 2	1.1/4	42.5	20	50	50	Body only
EVGE-42LR11/2ED	L	250	42	M52 x 2	1.1/2	46.5	22	55	60	Body only
EVGE-06SR1/4ED	S	800	6	M14 x 1.5	1/4	27	12	19	17	Body only
EVGE-08SR1/4ED	S	800	8	M16 x 1.5	1/4	29.5	12	19	19	Body only
EVGE-10SR3/8ED	S	800	10	M18 x 1.5	3/8	32	12	22	22	Body only
EVGE-12SR3/8ED	S	630	12	M20 x 1.5	3/8	34	12	22	24	Body only
EVGE-14SR1/2ED	S	630	14	M22 x 1.5	1/2	36.5	14	27	27	Body only
EVGE-16SR1/2ED	S	630	16	M24 x 1.5	1/2	37	14	27	30	Body only
EVGE-20SR3/4ED	S	630	20	M30 x 2	3/4	43	16	32	36	Body only
EVGE-25SR1ED	S	630	25	M36 x 2	1	48	18	41	46	Body only
EVGE-30SR11/4ED	S	420	30	M42 x 2	1.1/4	51	20	50	50	Body only
EVGE-38SR11/2ED	S	420	38	M52 x 2	1.1/2	60	22	55	60	Body only
