| Product code | KYA |
|---|---|
| Category | Hydraulic > Adaptors > Imperial > Tees/Test Point/Cross Adaptors |
| Product Code | Series | Thread E | Thread F | Thread G | Dimensions mm A | Dimensions mm B | Dimensions mm C | Dimensions mm S1 | Dimensions mm S2 |
|---|---|---|---|---|---|---|---|---|---|
| KYA-14-14-20 | KYA | M14 x 1.5 | M14 x 1.5 | M20 x 1.5 | 30 | 30 | 37 | 19 | 27 |
| KYA-18-18-14 | KYA | M18 x 1.5 | M18 x 1.5 | M14 x 1.5 | 30.5 | 30.5 | 35.5 | 19 | 19 |
| KYA-22-22-20 | KYA | M22 x 1.5 | M22 x 1.5 | M20 x 1.5 | 45.5 | 45.5 | 40 | 22 | 27 |
| KYA-22-22-22 | KYA | M22 x 1.5 | M22 x 1.5 | M22 x 1.5 | 45.5 | 45.5 | 40 | 22 | 27 |
