METRIC MALE x JIC MALE

21+

Locations New Zealand Wide

65+

Mobile Service Units

24/7

On-Site Hose Repair

IMPERIAL X METRIC

Product Details

Product code	L
Category	Hydraulic > Adaptors > Imperial x Metric > Straight Connectors

Product Table

Product Code	Series	Metric Thread	Imperial Thread	Dimensions mm A	Dimensions mm B	Dimensions mm L	Dimensions mm S1	Notes
L-08-07	L	M8 x 1	7/16 - 20	14	7	28	12	Non-Stocked; Requires bonded seal
L-10-07	L	M10 x 1	7/16 - 20	14	8	29.5	17
L-10-09	L	M10 x 1	9/16 - 18	14	8	29.5	14
L-12-07	L	M12 x 1.5	7/16 - 20	14	10	31	17
L-12-09	L	M12 x 1.5	9/16 - 18	14	12	33.5	17
L-14-07	L	M14 x 1.5	7/16 - 20	14	12	33.4	19
L-14-09	L	M14 x 1.5	9/16 - 18	14	12	34	19
L-14-12	L	M14 x 1.5	3/4 - 16	16.7	12	38.5	22
L-16-07	L	M16 x 1.5	7/16 - 20	14	12	36	14
L-16-09	L	M16 x 1.5	9/16 - 18	14	12	36	22
L-16-12	L	M16 x 1.5	3/4 - 16	16.7	12	38.5	22
L-16-14	L	M16 x 1.5	7/8 - 14	19	12	41	24
L-18-09	L	M18 x 1.5	9/16 - 18	14.1	12	36.5	24
L-18-12	L	M18 x 1.5	3/4 - 16	16.7	12	39	24
L-18-14	L	M18 x 1.5	7/8 - 14	19.3	12	41.5	24
L-18-17	L	M18 x 1.5	1.1/16 - 12	21.9	12	46.5	30
L-20-09	L	M20 x 1.5	9/16 - 18	14.1	14	40.5	27
L-20-12	L	M20 x 1.5	3/4 - 16	16.7	14	43	27
L-20-14	L	M20 x 1.5	7/8 - 14	19.3	14	45.5	27
L-22-12	L	M22 x 1.5	3/4 - 16	16.7	14	43.5	27
L-22-14	L	M22 x 1.5	7/8 - 14	19.3	14	46	27
L-22-17	L	M22 x 1.5	1.1/16 - 12	21.9	14	48.5	30
L-24-17	L	M24 x 1.5	1.1/16 - 12	22	14	48	30	Non-Stocked; Requires bonded seal
L-26-17	L	M26 x 1.5	1.1/16 - 12	21.9	16	52	32
L-26-21	L	M26 x 1.5	1.5/16 - 12	23.1	16	53	36
L-27-17	L	M27 x 2	1.1/16 - 12	21.9	16	52	32
L-27-21	L	M27 x 2	1.5/16 - 12	21.9	16	52	36
L-33-17	L	M33 x 2	1.1/16 - 12	21.9	18	52	38
L-33-21	L	M33 x 2	1.5/16 - 12	23.1	18	57	41
L-33-26	L	M33 x 2	1.5/8 - 12	24.3	18	58.2	46
L-42-26	L	M42 x 2	1.5/8 - 12	24.3	20	62	50
L-42-30	L	M42 x 2	1.7/8 - 12	27.5	20	64	50
L-48-26	L	M48 x 2	1.5/8 - 12	24.3	22	67.5	55
L-48-30	L	M48 x 2	1.7/8 - 12	27.5	22	67.5	55
