| Product code | NM1 R |
|---|---|
| Category | Hydraulic > Hose Tails > SAE/NPT |
| Product Code | Thread T | Thread Size | Nominal ID Dash | Nominal ID Inch | Nominal ID DN | Dimensions mm A | Dimensions mm B | Dimensions mm ES | Dimensions mm C |
|---|---|---|---|---|---|---|---|---|---|
| NM1-0404R | 1/4" - 18 | 4 | 4 | 3/16" | 5 | 25.8 | 14 | 14 | 21 |
| NM1-0606R | 3/8" - 18 | 6 | 6 | 5/16" | 8 | 28 | 14 | 19 | 24 |
| NM1-0808R | 1/2" - 14 | 8 | 8 | 13/32" | 11 | 33 | 19 | 22 | 27 |
| NM1-1212R | 3/4" - 14 | 12 | 12 | 5/8" | 16 | 41 | 19 | 27 | 37 |
| NM1-1616R | 1" - 11½ | 16 | 16 | 7/8" | 22 | 47.5 | 24 | 36 | 43 |
| NM1-2424R | 1.1/2" - 11½ | 24 | 24 | 1.3/8" | 35 | 60.5 | 25.5 | 50 | 54 |
