| Product code | NM1 P |
|---|---|
| Category | Hydraulic > Hose Tails > NPT Hose Tails |
| Product Code | Thread T | Thread Size | Thread Pipe | Hose Bore DN | Hose Bore Inch | Hose Bore Size | Dimensions mm A | Dimensions mm L | Dimensions mm S1 | Dimensions mm d |
|---|---|---|---|---|---|---|---|---|---|---|
| NM1-0204P | 1/8" - 27 | 2 | 1/8" | 6 | 1/4" | 4 | 16.5 | 35.6 | 11 | 4.3 |
| NM1-0404P | 1/4" - 18 | 4 | 1/4" | 6 | 1/4" | 4 | 21.1 | 40.1 | 14 | 4.3 |
| NM1-0406P | 1/4" - 18 | 4 | 1/4" | 10 | 3/8" | 6 | 22.6 | 44.7 | 14 | 7.6 |
| NM1-0606P | 3/8" - 18 | 6 | 3/8" | 10 | 3/8" | 6 | 22.6 | 44.7 | 19 | 7.6 |
| NM1-0608P | 3/8" - 18 | 6 | 3/8" | 12 | 1/2" | 8 | 22.6 | 48.5 | 19 | 9.9 |
| NM1-0808P | 1/2" - 14 | 8 | 1/2" | 12 | 1/2" | 8 | 29 | 54.9 | 22 | 9.9 |
| NM1-1212P | 3/4" - 14 | 12 | 3/4" | 20 | 3/4" | 12 | 30.7 | 69 | 27 | 15.5 |
