| Product code | OF1 R |
|---|---|
| Category | Hydraulic > Hose Tails > O-Ring Face Seal (ORFS) |
| Product Code | Thread T | Thread Size | Thread Pipe | 100R5 Bore Dash | 100R5 Bore Inch | 100R5 Bore DN | Dimensions mm A | Dimensions mm B | Dimensions mm CH | Dimensions mm ES | Dimensions mm C |
|---|---|---|---|---|---|---|---|---|---|---|---|
| OF1-0404R | 9/16" - 18 | 4 | 4 | 4 | 3/16" | 4 | 27.3 | 8 | 17 | 14 | 21 |
| OF1-0606R | 11/16" - 16 | 6 | 6 | 6 | 5/16" | 8 | 32 | 9.5 | 22 | 17 | 24 |
| OF1-0806R | 13/16" - 16 | 8 | 8 | 6 | 5/16" | 8 | 36.5 | 11 | 24 | 19 | 24 |
| OF1-0808R | 13/16" - 16 | 8 | 8 | 8 | 13/32" | 11 | 36.5 | 11 | 24 | 19 | 27 |
| OF1-0810R | 13/16" - 16 | 8 | 8 | 10 | 1/2" | 12 | 37 | 11 | 24 | 19 | 31 |
| OF1-1010R | 1" - 14 | 10 | 10 | 10 | 1/2" | 12 | 39 | 13.5 | 30 | 24 | 31 |
| OF1-1212R | 1.3/16" - 12 | 12 | 12 | 12 | 5/8" | 16 | 44 | 14.5 | 36 | 30 | 37 |
| OF1-1616R | 1.7/16" - 12 | 16 | 16 | 16 | 7/8" | 22 | 52.5 | 14.8 | 41 | 36 | 43 |
