| Product code | SF9 A |
|---|---|
| Category | Hydraulic > Hose Tails > SAE/UNO |
| Common Uses | Braided and general-purpose hydraulic hose applications | Field-attachable fittings for SAE R5 dimensioned hose; ferrule included | LPG hose applications | Thermoplastic and PTFE hose applications |
|---|---|
| Series | A | G | K | T |
| Product Series | SF9 |
| Application | General hydraulic rubber hose | LPG hose | SAE R5 field attachable | Thermoplastic / PTFE hose |
| Product Code | Thread E | Thread Size | Thread Pipe | 100R5 Bore DN | 100R5 Bore Inch | 100R5 Bore Size | Dimensions mm A | Dimensions mm C | Dimensions mm H | Dimensions mm S1 | Dimensions mm S2 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SF9-1006A | 5/8" - 18 | 10 | 6 | 8 | 5/16" | 6 | 33 | 11.3 | 21.3 | 12.7 | 19 |
| SF9-1712A | 1.1/16" - 14 | 17 | 12 | 16 | 5/8" | 12 | 55.1 | 18.5 | 46.2 | 22.1 | 31.7 |
