| Product code | SF1 T |
|---|---|
| Category | Hydraulic > Hose Tails > SAE/UNO |
| Product Code | Thread T | Thread Size | Thread Pipe | Hose Bore DN | Hose Bore Inch | Hose Bore Size | Dimensions mm A | Dimensions mm B | Dimensions mm CH | Dimensions mm ES |
|---|---|---|---|---|---|---|---|---|---|---|
| SF1-1004T | 5/8" - 18 | 10 | 6 | 6 | 1/4" | 4 | 23.9 | 10.8 | 22 | 19 |
| SF1-1006T | 5/8" - 18 | 10 | 6 | 10 | 3/8" | 6 | 23.9 | 10.8 | 22 | 19 |
| SF1-1712T | 1.1/16" - 14 | 17 | 12 | 20 | 3/4" | 12 | 31.2 | 14.4 | 32 | 27 |
