| Product code | SF1 A |
|---|---|
| Category | Hydraulic > Hose Tails > SAE/UNO |
| Product Code | Thread T | Thread Size | Thread Pipe | 100R5 Bore DN | 100R5 Bore Inch | 100R5 Bore Size | Dimensions mm A | Dimensions mm B | Dimensions mm CH | Dimensions mm ES |
|---|---|---|---|---|---|---|---|---|---|---|
| SF1-1006A | 5/8" - 18 | 10 | 6 | 8 | 5/16" | 6 | 23.9 | 10.8 | 22 | 19 |
| SF1-1712A | 1.1/16" - 14 | 17 | 12 | 16 | 5/8" | 12 | 31.2 | 14.4 | 32 | 27 |
