MSHA flame resistance. High temperature resistance.
| Product code | HT1 |
|---|---|
| Type | High-temperature one-wire hose — SAE 100R1AT, EN853 1SN |
| Standards/Approvals | Meets or exceeds SAE 100R1AT; EN853 1SN; AS 3791 100R1; ISO 1436 R1AT/1SN; MSHA flame resistance |
| Category | Hydraulic > Hose > Rubber > Braided |
| Inner Liner | High-temperature synthetic rubber; oil resistant |
|---|---|
| Outer Cover | Blue synthetic rubber resistant to abrasion, oils, ozone and weathering |
| Reinforcement | One braid of high-tensile steel wire |
| Application | Medium-pressure high-temperature hose for mineral and biological hydraulic oils, polyglycol-based oils, water-oil emulsions, water and compressed air. Pin-prick the cover when conveying air or gas above 17 bar. |
| Temperature range | Air: Up to +135°C with oil mist; not for dry air;; Ambient: -50°C to +120°C;; Hydraulic oils: -50°C to +135°C; occasional peaks to +150°C;; Polyglycol / water emulsions: Up to +85°C;; Rated range: -50°C to +120°C |
|---|---|
| Safety factor | 4:1 |
| Vacuum rating | N/A |
| Caution | The outer cover must be pin-pricked when the hose conveys air or gases above 17 bar. |
| Feature | High-temperature resistance |
|---|
| Item code | ID (inch) | ID (mm) | OD avg (mm) | Max WP (bar) | Max WP (psi) | Min bend radius (mm) | Weight (kg/m) |
|---|---|---|---|---|---|---|---|
| HT1-12 | 3/4 | 19.1 | 27.5 | 105 | 1,523 | 240 | 0.58 |
| HT1-16 | 1 | 25.4 | 35.4 | 88 | 1,276 | 300 | 0.88 |
| Hose size | Crimp |
|---|---|
| -12 | 2J |
| -16 | 2J |
