Straight Bulkhead Coupling

21+

Locations New Zealand Wide

65+

Mobile Service Units

24/7

On-Site Hose Repair

METRIC COMPRESSION

Product Details

Product code	SV
Category	Hydraulic > Adaptors > Metric Compression > Tube and Pipe

Product Table

Product Code	Series	Max Working Pressure bar	Tube Ø mm	Metric Tube Thread1	Dimensions mm L1	Dimensions mm L2	Dimensions mm L3	Dimensions mm L4	Dimensions mm L5	Dimensions mm L6	Dimensions mm CH1	Dimensions mm CH2	Dimensions mm CH3	Notes
SV-06L	L	315	6	M12 x 1.5	14	34	7	27	22	42	17	17	14
SV-06S	S	630	6	M14 x 1.5	19	36	12	29	27	44	19	19	17
SV-08L	L	315	8	M14 x 1.5	15	34	8	27	23	42	19	19	17
SV-08S	S	630	8	M16 x 1.5	20	36	13	29	28	44	22	22	19
SV-10L	L	315	10	M16 x 1.5	17	35	10	28	25	43	22	22	19
SV-10S	S	630	10	M18 x 1.5	22	37	14.5	29.5	31	46	24	24	22
SV-12L	L	315	12	M18 x 1.5	17	36	10	29	25	44	24	24	22
SV-12S	S	630	12	M20 x 1.5	22	38	14.5	30.5	31	47	27	27	24
SV-14S	S	630	14	M22 x 1.5	25	40	17	32	35	50	30	30	27
SV-15L	L	315	15	M22 x 1.5	19	38	12	31	27	46	27	30	27
SV-16S	S	400	16	M24 x 1.5	25	40	16.5	31.5	35	50	32	32	30
SV-18L	L	315	18	M26 x 1.5	21	40	13.5	32.5	30	49	32	36	32
SV-20S	S	400	20	M30 x 2	28	44	17.5	33.5	39	55	41	41	36
SV-22L	L	160	22	M30 x 2	24	42	16.5	34.5	33	51	36	41	36
SV-25S	S	400	25	M36 x 2	32	47	20	35	44	59	46	46	46
SV-28L	L	160	28	M36 x 2	26	43	18.5	35.5	35	52	41	46	41
SV-30S	S	400	30	M42 x 2	35	51	21.5	37.5	48	64	50	50	50
SV-35L	L	160	35	M45 x 2	29	47	18.5	36.6	40	58	50	55	50	Non-Stocked
SV-38S	S	315	38	M52 x 2	38	53	22	37	53	68	65	65	60
SV-42L	L	160	42	M52 x 2	30	47	19	36	42	59	60	65	60
