Straight Tube Coupling

21+

Locations New Zealand Wide

65+

Mobile Service Units

24/7

On-Site Hose Repair

METRIC COMPRESSION

Product Details

Product code	G
Category	Hydraulic > Adaptors > Metric Compression > Tube and Pipe

Product Table

Product Code	Series	Max Working Pressure bar	Tube Ø mm	Metric Tube Thread1	Dimensions mm W	Dimensions mm D1	Dimensions mm L1	Dimensions mm L2	Dimensions mm L3	Notes
G-04LL	LL	100	4	M8 x 1	20	12	31	12	10	Body only; Non-Stocked
G-06L	L	315	6	M12 x 1.5	24	10	39	12	14	Body only
G-06LL	LL	100	6	M10 x 1	20	9	32	12	12	Body only
G-06S	S	630	6	M14 x 1.5	30	16	45	14	17	Body only
G-08L	L	315	8	M14 x 1.5	25	11	40	14	17	Body only
G-08LL	LL	100	8	M12 x 1	23	12	35	12	14	Body only
G-08S	S	630	8	M16 x 1.5	32	18	47	17	19	Body only
G-10L	L	315	10	M16 x 1.5	27	13	42	17	19	Body only
G-10S	S	630	10	M18 x 1.5	32	17	49	19	22	Body only
G-12L	L	315	12	M18 x 1.5	28	14	43	19	22	Body only
G-12S	S	630	12	M20 x 1.5	34	19	51	22	24	Body only
G-14S	S	630	14	M22 x 1.5	38	22	57	24	27	Body only
G-15L	L	315	15	M22 x 1.5	30	16	46	24	27	Body only
G-16S	S	400	16	M24 x 1.5	38	21	57	27	30	Body only
G-18L	L	315	18	M26 x 1.5	31	16	48	27	32	Body only
G-20S	S	400	20	M30 x 2	44	23	66	32	36	Body only
G-22L	L	315	22	M30 x 2	35	20	52	32	36	Body only
G-25S	S	400	25	M36 x 2	50	26	74	41	46	Body only
G-28L	L	160	28	M36 x 2	36	21	54	41	41	Body only
G-30S	S	400	30	M42 x 2	54	27	80	46	50	Body only
G-35L	L	160	35	M45 x 2	41	20	63	46	50	Body only
G-38S	S	315	38	M52 x 2	61	29	90	55	60	Body only
G-42L	L	160	42	M52 x 2	43	21	66	55	60	Body only
