IMPERIAL

Product Details

Product code	AS
Category	Hydraulic > Adaptors > Imperial > PLUGS

Common Uses	Compression fittings for metric hydraulic tube and pipe connections
Series	L / S
Product Series	AS
Application	Metric tube and pipe systems

Product Table

Product Code	Series	Max Working Pressure bar	Tube Ø mm	Dimensions mm D1	Dimensions mm L1	Dimensions mm L2	Dimensions mm L3	Dimensions mm CH1	Dimensions mm CH2	Notes
AS-06L	L	315	6	10	14	21	29	12	14	Body only; Non-Stocked
AS-08L	L	315	8	12	16	23	31	14	17	Body only
AS-10L	L	315	10	14	18	25	33	17	19	Body only; Non-Stocked
AS-12L	L	315	12	16	18	25	33	19	22	Body only; Non-Stocked
AS-15L	L	315	15	19	22	29	37	22	27	Body only; Non-Stocked
AS-18L	L	315	18	22	23.5	31	40	27	32	Body only
AS-22L	L	315	22	27	28.5	36	45	32	36	Body only; Non-Stocked
AS-28L	L	160	28	32	30.5	38	47	41	41	Body only; Non-Stocked
AS-35L	L	160	35	40	32.5	43	54	46	50	Body only; Non-Stocked
AS-42L	L	160	42	46	35	46	58	55	60	Body only; Non-Stocked
AS-06S	S	630	6	11	19	26	34	14	17	Body only
AS-08S	S	630	8	13	21	28	36	17	19	Body only
AS-10S	S	630	10	15	22.5	30	39	19	22	Body only
AS-12S	S	630	12	17	24.5	32	41	22	24	Body only
AS-14S	S	630	14	19	27	35	45	24	27	Body only; Non-Stocked
AS-16S	S	630	16	21	26.5	35	45	27	30	Body only
AS-20S	S	400	20	26	29.5	40	51	32	36	Body only
AS-25S	S	400	25	31	32	44	56	41	46	Body only
AS-30S	S	400	30	36	35.5	49	62	46	50	Body only
AS-38S	S	315	38	44	38	54	69	55	60	Body only
