Adjustable Barrel Tee Coupling

21+

Locations New Zealand Wide

65+

Mobile Service Units

24/7

On-Site Hose Repair

METRIC COMPRESSION

Product Details

Product code	EVL
Category	Hydraulic > Adaptors > Metric Compression > Tube and Pipe

Product Table

Product Code	Series	Max Working Pressure bar	Tube Ø mm	Thread m	Dimensions mm L1	Dimensions mm L2	Dimensions mm L3	Dimensions mm L4	Dimensions mm CH1	Dimensions mm CH2	Notes
EVL-06L	L	315	6	M12 x 1.5	19	12	26	27	12	14	Body only
EVL-08L	L	315	8	M14 x 1.5	21	14	27.5	29	12	17	Body only
EVL-10L	L	315	10	M16 x 1.5	22	15	29	30	14	19	Body only
EVL-12L	L	315	12	M18 x 1.5	24	17	29.5	32	17	22	Body only
EVL-15L	L	315	15	M22 x 1.5	28	21	32.5	36	19	27	Body only
EVL-18L	L	315	18	M26 x 1.5	31	23.5	35.5	40	24	32	Body only
EVL-22L	L	315	22	M30 x 2	35	27.5	38.5	44	27	36	Body only
EVL-28L	L	160	28	M36 x 2	38	30.5	41.5	47	36	41	Body only
EVL-35L	L	160	35	M45 x 2	45	34.5	51.5	56	41	50	Body only
EVL-42L	L	160	42	M52 x 2	51	40	56	63	50	60	Body only
EVL-06S	S	630	6	M14 x 1.5	23	16	27	31	12	17	Body only
EVL-08S	S	630	8	M16 x 1.5	24	17	27.5	32	14	19	Body only
EVL-10S	S	630	10	M18 x 1.5	25	17.5	30	34	17	22	Body only
EVL-12S	S	630	12	M20 x 1.5	29	21.5	31	38	17	24	Body only
EVL-14S	S	630	14	M22 x 1.5	30	22	35	40	19	27	Body only
EVL-16S	S	630	16	M24 x 1.5	33	24.5	36.5	43	24	30	Body only
EVL-20S	S	400	20	M30 x 2	37	26.5	44.5	48	27	36	Body only
EVL-25S	S	400	25	M36 x 2	42	30	50	54	36	46	Body only
EVL-30S	S	400	30	M42 x 2	49	35.5	55.5	62	41	50	Body only
EVL-38S	S	315	38	M52 x 2	57	41	63	72	50	60	Body only
