| Product code | D Cutting Ring |
|---|---|
| Category | Hydraulic > Adaptors > Metric Compression > Tube and Pipe |
| Product Code | Series | Max Working Pressure bar | Tube Ø mm | Dimensions mm L1 | Dimensions mm D1 | Dimensions mm D2 |
|---|---|---|---|---|---|---|
| D-04LL | LL | 100 | 4 | 6 | 6 | |
| D-06LL | LL | 100 | 6 | 7 | 8 | |
| D-08LL | LL | 100 | 8 | 7 | 10 | |
| D-06L/S | L / S | 315 / 630 | 6 | 9.5 | 10 | 10 |
| D-08L/S | L / S | 315 / 630 | 8 | 9.5 | 12 | 12 |
| D-10L/S | L / S | 315 / 630 | 10 | 10 | 14 | 14 |
| D-12L/S | L / S | 315 / 630 | 12 | 10 | 16 | 16 |
| D-15L | L | 315 | 15 | 10 | 19 | 20 |
| D-18L | L | 315 | 18 | 10 | 23 | 23 |
| D-22L | L | 315 | 22 | 10.5 | 27 | 27 |
| D-28L | L | 160 | 28 | 11 | 33 | 33 |
| D-35L | L | 160 | 35 | 13 | 41 | 41 |
| D-42L | L | 160 | 42 | 13 | 48 | 48 |
| D-14S | S | 630 | 14 | 10 | 19 | 19 |
| D-16S | S | 630 | 16 | 10.5 | 21 | 21 |
| D-20S | S | 400 | 20 | 12 | 26 | 26 |
| D-25S | S | 400 | 25 | 12 | 32 | 32 |
| D-30S | S | 400 | 30 | 13 | 36 | 38 |
| D-38S | S | 315 | 38 | 13 | 44 | 48 |
