| Product code | JFC9 F |
|---|---|
| Category | Hydraulic > Hose Tails > JIC Hose Tails |
| Product Code | Thread T | Thread Size | Thread Pipe | Nominal ID DN | Nominal ID Inch | Nominal ID Dash | Dimensions mm B | Dimensions mm CH |
|---|---|---|---|---|---|---|---|---|
| JFC9-0704F | 7/16" - 20 | 7 | 4 | 6 | 1/4" | 4 | 8.5 | 15 |
| JFC9-0804F | 1/2" - 20 | 8 | 5 | 6 | 1/4" | 4 | 9.5 | 17 |
| JFC9-0904F | 9/16" - 18 | 9 | 6 | 6 | 1/4" | 4 | 9.5 | 19 |
| JFC9-1206F | 3/4" - 16 | 12 | 8 | 10 | 3/8" | 6 | 10.7 | 24 |
| JFC9-1208F | 3/4" - 16 | 12 | 8 | 12 | 1/2" | 8 | 10.7 | 24 |
| JFC9-1408F | 7/8" - 14 | 14 | 10 | 12 | 1/2" | 8 | 12.7 | 27 |
