| Product code | OF4 T |
|---|---|
| Category | Hydraulic > Hose Tails > O-Ring Face Seal (ORFS) |
| Product Code | Thread T | Thread Size | Thread Pipe | Hose Bore DN | Hose Bore Inch | Hose Bore Size | Dimensions mm A | Dimensions mm B | Dimensions mm D | Dimensions mm CH |
|---|---|---|---|---|---|---|---|---|---|---|
| OF4-0404T | 9/16" - 18 | 4 | 4 | 6 | 1/4" | 4 | 43.5 | 8 | 11 | 19 |
| OF4-0604T | 11/16" - 16 | 6 | 6 | 6 | 1/4" | 4 | 36 | 9.5 | 15 | 22 |
| OF4-0606T | 11/16" - 16 | 6 | 6 | 10 | 3/8" | 6 | 47.5 | 9.5 | 15 | 22 |
| OF4-0806T | 13/16" - 16 | 8 | 8 | 10 | 3/8" | 6 | 43.5 | 11 | 15 | 24 |
| OF4-0808T | 13/16" - 16 | 8 | 8 | 12 | 1/2" | 8 | 56.5 | 11 | 14 | 24 |
| OF4-1010T | 1" - 14 | 10 | 10 | 16 | 5/8" | 10 | 56.5 | 13.5 | 21 | 30 |
| OF4-1210T | 1.3/16" - 12 | 12 | 12 | 16 | 5/8" | 10 | 60.5 | 14.5 | 23.2 | 36 |
| OF4-1212T | 1.3/16" - 12 | 12 | 12 | 20 | 3/4" | 12 | 64.4 | 14.5 | 21.5 | 36 |
