| Product code | VSTI |
|---|---|
| Category | Hydraulic > Adaptors > Metric Compression > Tube and Pipe |
| Product Code | Series | Max Working Pressure bar | Port Thread | Dimensions mm D1 | Dimensions mm L1 | Dimensions mm L2 | Dimensions mm CH1 | Notes |
|---|---|---|---|---|---|---|---|---|
| VSTI-10x1 | S | 400 | M10 x 1 | 14 | 12 | 8 | 5 | Elastomer seal (ED) |
| VSTI-12x1.5 | S | 400 | M12 x 1.5 | 17 | 17 | 12 | 6 | Elastomer seal (ED) |
| VSTI-14x1.5 | S | 400 | M14 x 1.5 | 19 | 17 | 12 | 6 | Elastomer seal (ED) |
| VSTI-16x1.5 | S | 400 | M16 x 1.5 | 22 | 17 | 12 | 8 | Elastomer seal (ED) |
| VSTI-18x1.5 | S | 400 | M18 x 1.5 | 24 | 17 | 12 | 8 | Elastomer seal (ED) |
| VSTI-20x1.5 | S | 400 | M20 x 1.5 | 26 | 19 | 14 | 10 | Elastomer seal (ED) |
| VSTI-22x1.5 | S | 400 | M22 x 1.5 | 27 | 19 | 14 | 10 | Elastomer seal (ED) |
| VSTI-24x1.5 | S | 400 | M24 x 1.5 | 29 | 20 | 15 | 12 | Elastomer seal (ED) |
| VSTI-26x1.5 | S | 400 | M26 x 1.5 | 32 | 21 | 16 | 12 | Elastomer seal (ED) |
| VSTI-27x2.0 | S | 400 | M27 x 2.0 | 32 | 21 | 16 | 12 | Elastomer seal (ED) |
| VSTI-33x2.0 | S | 400 | M33 x 2.0 | 40 | 22.5 | 16 | 17 | Elastomer seal (ED) |
| VSTI-42x2.0 | S | 250 | M42 x 2.0 | 50 | 22.5 | 16 | 22 | Elastomer seal (ED) |
| VSTI-48x2.0 | S | 250 | M48 x 2.0 | 55 | 22.5 | 16 | 24 | Elastomer seal (ED) |
