Straight Reducing Coupling

21+

Locations New Zealand Wide

65+

Mobile Service Units

24/7

On-Site Hose Repair

METRIC COMPRESSION

Straight Reducing Coupling

Product Details

Product Overview

Product code	GV
Category	Hydraulic > Adaptors > Metric Compression > Tube and Pipe

Product Table

Product Code	Series	Max Working Pressure bar	Tube Ø mm D1	Tube Ø mm D2	Metric Tube Thread1	Metric Tube Thread2	Dimensions mm L1	Dimensions mm L2	Dimensions mm L3	Dimensions mm CH1	Dimensions mm CH2	Dimensions mm CH3	Notes
GV-06LL/04LL	LL	100	6	4	M10 x 1	M8 x 1							Body only; Non-Stocked
GV-08L/06L	L	315	8	6	M14 x 1.5	M12 x 1.5	25	11	40.5	14	17	14	Body only; Non-Stocked
GV-08LL/04LL	LL	100	8	4	M12 x 1	M8 x 1							Body only; Non-Stocked
GV-08LL/06LL	LL	100	8	6	M12 x 1	M10 x 1							Body only; Non-Stocked
GV-08S/06S	S	630	8	6	M16 x 1.5	M14 x 1.5	32	18	48	17	19	17	Body only; Non-Stocked
GV-10L/06L	L	315	10	6	M16 x 1.5	M12 x 1.5	26	12	41.5	17	19	14	Body only
GV-10L/08L	L	315	10	8	M16 x 1.5	M14 x 1.5	26	12	42	17	19	17	Body only; Non-Stocked
GV-10S/06S	S	630	10	6	M18 x 1.5	M14 x 1.5	32	17.5	48.5	19	22	17	Body only; Non-Stocked
GV-10S/08S	S	630	10	8	M18 x 1.5	M16 x 1.5	32	17.5	48.5	19	22	19	Body only; Non-Stocked
GV-12L/06L	L	315	12	6	M18 x 1.5	M12 x 1.5	27	13	42	19	22	14	Body only; Non-Stocked
GV-12L/08L	L	315	12	8	M18 x 1.5	M14 x 1.5	27	13	42.5	19	22	17	Body only; Non-Stocked
GV-12L/10L	L	315	12	10	M18 x 1.5	M16 x 1.5	28	14	43.5	19	22	19	Body only
GV-12S/06S	S	630	12	6	M20 x 1.5	M14 x 1.5	34	19.5	50.5	22	24	17	Body only; Non-Stocked
GV-12S/08S	S	630	12	8	M20 x 1.5	M16 x 1.5	34	19.5	50.5	22	24	19	Body only; Non-Stocked
GV-12S/10S	S	630	12	10	M20 x 1.5	M18 x 1.5	34	19	51	22	24	22	Body only; Non-Stocked
GV-14S/10S	S	630	14	10	M22 x 1.5	M18 x 1.5	36	20.5	54.5	24	27	22	Body only; Non-Stocked
GV-14S/12S	S	630	14	12	M22 x 1.5	M20 x 1.5	36	20.5	54.5	24	27	24	Body only; Non-Stocked
GV-15L/10L	L	315	15	10	M22 x 1.5	M16 x 1.5	29	15	45	24	27	19	Body only; Non-Stocked
GV-15L/12L	L	315	15	12	M22 x 1.5	M18 x 1.5	29	15	44.5	24	27	22	Body only
GV-16S/12S	S	630	16	12	M24 x 1.5	M20 x 1.5	36	20	54.5	27	30	24	Body only; Non-Stocked
GV-16S/14S	S	630	16	14	M24 x 1.5	M22 x 1.5	38	21.5	58	27	30	27	Body only; Non-Stocked
GV-18L/10L	L	315	18	10	M26 x 1.5	M16 x 1.5	30	15.5	47	27	32	19	Body only; Non-Stocked
GV-18L/12L	L	315	18	12	M26 x 1.5	M18 x 1.5	30	15.5	46.5	27	32	22	Body only; Non-Stocked
GV-18L/15L	L	315	18	15	M26 x 1.5	M22 x 1.5	31	16.5	48	27	32	27	Body only; Non-Stocked
GV-20S/10S	S	400	20	10	M30 x 2	M18 x 1.5	40	22	59.5	32	36	22	Body only; Non-Stocked
GV-20S/12S	S	400	20	12	M30 x 2	M20 x 1.5	40	22	59.5	32	36	24	Body only; Non-Stocked
GV-20S/16S	S	400	20	16	M30 x 2	M24 x 1.5	42	23	63	32	36	30	Body only; Non-Stocked
GV-22L/12L	L	315	22	12	M30 x 2	M18 x 1.5	32	17.5	48.5	32	36	22	Body only; Non-Stocked
GV-22L/15L	L	315	22	15	M30 x 2	M22 x 1.5	33	18.5	50	32	36	27	Body only; Non-Stocked
GV-22L/18L	L	315	22	18	M30 x 2	M26 x 1.5	33	18	51	32	36	32	Body only; Non-Stocked
GV-25S/16S	S	400	25	16	M36 x 2	M24 x 1.5	46	25.5	68	41	46	30	Body only; Non-Stocked
GV-25S/20S	S	400	25	20	M36 x 2	M30 x 2	48	25.5	71	41	46	36	Body only; Non-Stocked
GV-28L/18L	L	160	28	18	M36 x 2	M26 x 1.5	34	19	52	41	41	32	Body only; Non-Stocked
GV-28L/22L	L	160	28	22	M36 x 2	M30 x 2	36	21	54	41	41	36	Body only; Non-Stocked
GV-30S/20S	S	400	30	20	M42 x 2	M30 x 2	50	26	74	46	50	36	Body only; Non-Stocked
GV-30S/25S	S	400	30	25	M42 x 2	M36 x 2	52	26.5	77	46	50	46	Body only; Non-Stocked
GV-35L/22L	L	160	35	22	M45 x 2	M30 x 2	39	21	59	46	50	36	Body only; Non-Stocked
GV-35L/28L	L	160	35	28	M45 x 2	M36 x 2	39	21	59	46	50	41	Body only; Non-Stocked
GV-38S/30S	S	315	38	30	M52 x 2	M42 x 2	59	29.5	87	55	60	50	Body only; Non-Stocked
