| Product code | EDKO |
|---|---|
| Category | Hydraulic > Adaptors > Metric Compression > Tube and Pipe |
| Product Code | Series | Max Working Pressure bar | Tube Ø mm | Thread m | Dimensions mm L1 | Dimensions mm CH1 | Notes |
|---|---|---|---|---|---|---|---|
| EDKO-06L | L | 315 | 6 | M12 x 1.5 | 40 | 14 | |
| EDKO-08L | L | 315 | 8 | M14 x 1.5 | 40 | 17 | |
| EDKO-10L | L | 315 | 10 | M16 x 1.5 | 39 | 19 | |
| EDKO-12L | L | 315 | 12 | M18 x 1.5 | 39 | 22 | |
| EDKO-15L | L | 315 | 15 | M22 x 1.5 | 45 | 27 | |
| EDKO-18L | L | 315 | 18 | M26 x 1.5 | 43 | 32 | |
| EDKO-22L | L | 315 | 22 | M30 x 2 | 48 | 36 | |
| EDKO-28L | L | 160 | 28 | M36 x 2 | 49 | 41 | |
| EDKO-35L | L | 160 | 35 | M45 x 2 | 60 | 50 | Non-Stocked |
| EDKO-42L | L | 160 | 42 | M52 x 2 | 60 | 60 | |
| EDKO-06S | S | 630 | 6 | M14 x 1.5 | 37 | 17 | |
| EDKO-08S | S | 630 | 8 | M16 x 1.5 | 38 | 19 | |
| EDKO-10S | S | 630 | 10 | M18 x 1.5 | 44 | 22 | |
| EDKO-12S | S | 630 | 12 | M20 x 1.5 | 41 | 24 | |
| EDKO-14S | S | 630 | 14 | M22 x 1.5 | 44 | 27 | |
| EDKO-16S | S | 630 | 16 | M24 x 1.5 | 51 | 30 | |
| EDKO-20S | S | 400 | 20 | M30 x 2 | 56 | 36 | |
| EDKO-25S | S | 400 | 25 | M36 x 2 | 60 | 46 | |
| EDKO-30S | S | 400 | 30 | M42 x 2 | 62 | 50 | |
| EDKO-38S | S | 315 | 38 | M52 x 2 | 70 | 60 | Non-Stocked |
